Category : Cisco Wireless

Cisco Meraki MR76 - Wireless Access Point

Outdoor and Industrial Wi-Fi 6 External Antennas and Integrated, Dedicated Security and Bluetooth?Radios

Brand : Cisco

Model : MR76

Enquiry Us Contact Now

Highlights

Ideal use cases

  • Harsh, industrial, and outdoor environments
  • Voice, video, and performance-intensive networks

Hardware features

  • IP67 rated: tested for dust, shock, vibration, and moisture
  • 4 radios: 2.4 GHz, 5 GHz, dual-band WIDS/WIPS, and Bluetooth
  • 2-stream UL/DL MU-MIMO 802.11ax up to 1.7 Gbps dual aggregate frame rate
  • Gigabit Ethernet port, 802.3af PoE compatible

Cloud management

  • Network-wide visibility and control
  • Self-provisioning for rapid deployment
  • Automatic reporting
  • Seamless firmware updates

Enterprise security

  • 802.1X and native Active Directory integration
  • Air Marshal: real-time WIPS with forensics
  • Stateful Layer 3-7 firewall
  • Identity-based group policies
  • Built-in antivirus scan (NAC)
  • Built-in Umbrella DNS Security*
  • Adaptive Policy automated segmentation**

Guest access

  • 1-click secure guest access
  • Guest isolation firewall
  • Customizable splash pages
  • Integrated Facebook WiFi login

RF optimization

  • Cloud-based RF planning
  • Built-in spectrum analysis
  • Dual-concurrent radios with band steering

Traffic Analytics

  • Classifies hundreds of applications
  • Create per-application and per-device bandwidth limits
  • Prioritize productivity apps
  • Restrict recreational traffic

Location Analytics

  • Measure visitor capture rate, visit length, and repeat visit rate
  • Measure visitor trends over time and compare performance across locations
  • Enable location services through integrated iBeacon functionality

Device management

  • Create device-specific firewall rules
  • Deploy applications and updates
  • Troubleshoot issues with built-in RDP

Mesh

  • Self-configuring, self-optimizing mesh
  • High performance multi-radio routing protocols
  • Extends coverage to hard-to-wire areas
  • Self-heals after cable or switch failures


Specifications

Radios

  • 2.4 GHz 802.11b/g/n/ax client access radio
  • 5 GHz 802.11a/n/ac/ax client access radio
  • 2.4 GHz and 5 GHz dual-band WIDS/WIPS, spectrum analysis, and location analytics radio
  • 2.4 GHz Bluetooth Low Energy radio with Beacon and Bluetooth Low Energy scanning support
  • Max data rate 1.7 Gbit/s
  • Operating Bands (country-specific restrictions apply)
    • 2.412-2.484 GHz
    • 5.150-5.250 GHz (UNII-1)
    • 5.250-5.350 GHZ (UNII-2)
    • 5.470-5.600 GHz, 5.650-5.725 GHz (UNII-2e)
    • 5.725-5.825 GHz (UNII-3)

802.11ax, 802.11ac Wave 2, and 802.11n Capabilities

  • UL/DL OFDMA, TWT support, BSS coloring
  • 2×2 multiple input, multiple output (MIMO) with 2 spatial streams
  • UL/DL SU-MIMO and MU-MIMO Support
  • Maximal ratio combining (MRC) & Beamforming
  • 20 and 40 MHz channels (802.11n); 20, 40, and 80 MHz channels (802.11ac Wave 2); 20, 40 and 80 MHz channels (802.11ax)
  • Up to 1024 QAM on both 2.4 GHz and 5 GHz bands
  • Packet aggregation

Power

  • Power over Ethernet: 37 - 57 V (802.3af compatible)
  • Power consumption: 15 W max
  • Power over Ethernet injector sold separately

Mounting

  • Mounts to walls and horizontal, vertical, and angled poles
  • Mounting hardware included

Physical Security

  • Security screw included
  • Anti-tamper cable bay
  • Concealed mount plate

Environment

  • Operating temperature: -40°F to 131°F (-40°C to 55°C)
  • IP67 environmental rating (sealed against water and dust)

Physical Dimensions

  • 11.81” x 6.02” x 2.16” (30.0 cm X 15.3 cm X 5.5 cm), not including cable gland, mounts and antennas
  • Weight: 47.27 oz (1.34 kg)

Interfaces

  • 1x 10/100/1000 BASE-T Ethernet (RJ45)

Security

  • Integrated Layer 7 firewall with mobile device policy management
  • Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal
  • Flexible guest access with device isolation
  • WEP**, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 - Personal**, WPA3 - Enterprise**, WPA3 - Enhanced Open (OWE)**
  • EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
  • PCI compliance reporting
  • TKIP and AES encryption
  • Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
  • Cisco ISE integration for Guest access and BYOD Posturing

Quality of Service

  • Advanced Power Save (U-APSD)
  • WMM Access Categories with DSCP and 802.1p support
  • Layer 7 application traffic identification and shaping

Mobility

  • PMK, OKC, & 802.11r for fast Layer 2 roaming
  • 802.11r and 802.11k
  • Distributed or centralized layer 3 roaming

LED Indicators

  • 4 signal strength
  • 1 Ethernet connectivity
  • 1 power/booting/firmware upgrade status

Regulatory

  • RoHS

Warranty

  • 1 year hardware warranty with advanced replacement included

Ordering Information

  • MR76-HW Meraki MR76 Cloud Managed 802.11ax AP
  • MA-INJ-5-XX Meraki Multigigabit 802.3at Power over Ethernet Injector (XX = US/EU/UK/AU)
  • MA-INJ-4-XX Meraki Gigabit 802.3at Power over Ethernet Injector (XX = US/EU/UK/AU)
  • MA-ANT-20 Meraki Dual-Band Omni Antennas
  • MA-ANT-21 Meraki 5 GHz Sector Antenna
  • MA-ANT-23 Meraki 2.4 GHz Sector Antenna
  • MA-ANT-25  Meraki Dual-Band Patch Antenna
  • MA-ANT-27 Meraki Dual-Band Sector Antenna
